Product Description
Grade A LiFePO4 Cells Home Solar Energy Storage Battery 3.2V 320ah Lifepo4 Battery
Features
The Grade A LiFePO4 Cells Home Solar Energy Storage Battery is a high-quality and reliable energy storage solution designed for residential solar applications. With a voltage of 3.2V and a capacity of 320Ah, this battery offers ample storage capacity for excess solar energy generated during the day. Its compact dimensions of 20771.1173.9(mm) make it suitable for installations with limited space.
Featuring Grade A LiFePO4 cells, this battery ensures exceptional performance, stability, and longevity. It has a long cycle life, allowing it to endure a large number of charge and discharge cycles without significant capacity degradation. The battery's LiFePO4 chemistry provides excellent safety, thermal stability, and reduced risk of thermal runaway.
Designed specifically for home solar energy storage, this battery allows homeowners to store solar energy and utilize it during periods of low solar generation or at night. It optimizes energy efficiency, minimizing energy loss during charge and discharge cycles.
Overall, the Grade A LiFePO4 Cells Home Solar Energy Storage Battery offers a reliable, safe, and efficient solution for residential solar energy storage, empowering homeowners to maximize the utilization of their solar power systems.
| Cell Type: | LiFePO4 (LFP) |
| Nominal Voltage: | 3.2V |
| Nominal Capacity: | 320Ah |
| Norminal Energy: | 966.4Wh |
| Dimension (L*W*H): | 207(H)*71.7(T)*173.9(W)mm |
| Series / Parallel Number: | 5.51±0.3kg |
| Charge Cut-off Voltage | 3.65V |
| Discharge Cut-off Voltage | 2.5V |
| Impedance Resistance (1khz) | ≤0.18mΩ |
| Cycle Life (25°C@80% DOD) | 6000 Cycles |
| Operating Temperature and Humidity Range | Charge: 0~45°C
Discharge: -10~60°C |
| Max. Paulse Charge/Discharge Current | 1C(30s) |
| Warranty: | 3 Years |
CUSTOM BATTERY SOLUTIONS
Redway Battery specializes in providing a diverse selection of battery sizes and configurations to cater to a wide range of applications. Whether you need standard battery options or have unique power requirements, our team of experienced engineers is here to assist you throughout the entire process of designing, developing, testing, and manufacturing custom battery solutions tailored to your specific needs. Feel free to reach out to us today to learn more about our comprehensive range of battery solutions and how we can create a customized solution for you.
All Redway Products Come with:
REDWAY PROMISE
6000 TIMES CYCLES ISO9001,ISO14001, OHSAS18001, EXW, FOB, DAP,DDP
3 YEARS WARRANTY CE, CB, UL, KC, FCC, BIS, IEC62133. T/T, L/C OPTIONAL
